Requirements and Acceptance for Cable and Wire Harness Assemblies
standard by Association Connecting Electronics Industries, 10/01/2022
IPC A 620 prescribes practices and requirements for the manufacture of cable, wire and harness assemblies. This standard does not provide criteria for cross-section or X-ray evaluation. For X-ray guidelines, see Appendix D X-Ray Guidelines.
If a conflict occurs between the English and translated versions of this document, the English version will take precedence.
The illustrations in this document portray specific points noted in the title of each section. The development committee recognizes that different parts of the industry have different definitions for some terms used herein. For the purposes of this document, the terms cable and wire harness are used interchangeably.
IPC/WHMA-A-620 can be used as a stand-alone document for purchasing products, however it does not specify frequency of in-process inspection or frequency of end product inspection. No limit is placed on the number of process indicators or the number of allowable repair/rework of defects. Such information should be developed with a statistical process control plan (see IPC 9191).
Number of Pages:388
File Size:1 file , 27 MB
Product Code(s):A620-STD-0-D-0-EN-E, A620-STD-0-D-0-EN-E
